Reactive Messaging

Overview

Asynchronous messaging is a commonly used form of communication in the world of microservices. While it is possible to start building your reactive streams directly by combining operators and connecting them to reactive APIs, with Helidon SE Reactive Messaging, you can now use prepared tools for repetitive use case scenarios .

Maven Coordinates

To enable Reactive Messaging, add the following dependency to your project’s pom.xml (see Managing Dependencies).

pom.xml

<dependency>
  <groupId>io.helidon.messaging</groupId>
  <artifactId>helidon-messaging</artifactId>
</dependency>

Usage

Connecting your streams to external services usually requires a lot of boilerplate code for configuration handling, backpressure propagation, acknowledgement and more.

In Helidon there is a system of connectors, emitters and means to orchestrate these tasks called Reactive Messaging. It’s basically an API for connecting and configuring connectors and emitters with your reactive streams through Channels.

Reactive Messaging relates to MicroProfile Reactive Messaging as the making of connectors and configuring them can be a repetitive task that ultimately leads to the same results. Helidon SE Reactive Messaging supports the very same configuration format for connectors as its MicroProfile counterpart does. Also, MP Connectors are reusable in Helidon SE Messaging with some limitations such as there is no CDI in Helidon SE. All Messaging connectors in Helidon are made to be universally usable by Helidon MP and SE.

Channel

A channel is a named pair of Publisher and Subscriber. Channels can be connected together by processors. Registering a Publisher or Subscriber for a channel can be done by Messaging API, or configured implicitly using registered connectors to generate the Publisher or Subscriber.

Example of simple channel:

Channel<String> channel1 = Channel.create("channel1");
Messaging.builder()
        .publisher(channel1, Multi.just("message 1", "message 2")
                .map(Message::of))
        .listener(channel1, s -> System.out.println("Intecepted message " + s))
        .build()
        .start();

Processor

Processor is a typical reactive processor acting as a Subscriber to upstream and as a Publisher to downstream. In terms of reactive messaging, it is able to connect two channels to one reactive stream.

Example of processor usage:

Channel<String> firstChannel = Channel.create("first-channel");
Channel<String> secondChannel = Channel.create("second-channel");

Messaging.builder()
        .publisher(secondChannel, Multi.just("test1", "test2", "test3")
                .map(Message::of))
        .processor(secondChannel, firstChannel, ReactiveStreams.<Message<String>>builder()
                .map(Message::getPayload)
                .map(String::toUpperCase)
                .map(Message::of))
        .subscriber(firstChannel, ReactiveStreams.<Message<String>>builder()
                .peek(Message::ack)
                .map(Message::getPayload)
                .forEach(s -> System.out.println("Consuming message " + s)))
        .build()
        .start();
// >Consuming message TEST1
// >Consuming message TEST2
// >Consuming message TEST3

Message

Reactive Messaging in Helidon SE uses the same concept of message wrapping as MicroProfile messaging. The only notable difference is that SE Messaging does almost no implicit or automatic acknowledgement due to no magic philosophy of Helidon SE.

The only exception to this are the variants of the methods Messaging.Builder#listener and Messaging.Builder#processor configured with consumer or function parameters which will conveniently unwrap the payload for you. Once the payload is automatically unwrapped, it is not possible to do a manual acknowledgement, therefore an implicit acknowledgement is executed before the callback.

Connectors

Connectors are used to connect channels to external sources. To make the creation and usage of connectors as easy and versatile as possible, Helidon SE Messaging uses the same API for connectors that MicroProfile Reactive Messaging does. This allows connectors to be used in both flavors of Helidon with one limitation which is that the connector has to be able to work without CDI.

Examples of versatile connectors in Helidon include the following:

Kafka connector
JMS connector
AQ Connector

Messaging Connector

A connector for Reactive Messaging is a factory that produces Publishers and Subscribers for Channels in Reactive Messaging. Messaging connector is just an implementation of IncomingConnectorFactory, OutgoingConnectorFactory or both.

Example connector example-connector:

@Connector("example-connector")
public class ExampleConnector implements IncomingConnectorFactory, OutgoingConnectorFactory {

    @Override
    public PublisherBuilder<? extends Message<?>> getPublisherBuilder(Config config) {
        return ReactiveStreams.of("foo", "bar")
                .map(Message::of);
    }

    @Override
    public SubscriberBuilder<? extends Message<?>, Void> getSubscriberBuilder(Config config) {
        return ReactiveStreams.<Message<?>>builder()
                .map(Message::getPayload)
                .forEach(o -> System.out.println("Connector says: " + o));
    }
}

Example of channel to connector mapping config:

mp.messaging.outgoing.to-connector-channel.connector: example-connector
mp.messaging.incoming.from-connector-channel.connector: example-connector

Example producing to connector:

Messaging.builder()
        .config(config)
        .connector(new ExampleConnector())
        .publisher(Channel.create("to-connector-channel"),
                   ReactiveStreams.of("fee", "fie")
                           .map(Message::of))
        .build()
        .start();

// > Connector says: fee
// > Connector says: fie

Example consuming from connector:

Messaging.builder()
        .config(config)
        .connector(new ExampleConnector())
        .subscriber(Channel.create("from-connector-channel"),
                    ReactiveStreams.<Message<String>>builder()
                            .peek(Message::ack)
                            .map(Message::getPayload)
                            .forEach(s -> System.out.println("Consuming: " + s)))
        .build()
        .start();

// > Consuming: foo
// > Consuming: bar

Configuration for Messaging Connector

A messaging connector in Helidon SE can be configured explicitly by API or implicitly by config following the notation of MicroProfile Reactive Messaging.

Configuration that is supplied to connector by the Messaging implementation must include two mandatory attributes:

channel-name which is the name of the channel that has the connector configured as Publisher or Subscriber, or Channel.create('name-of-channel') in case of explicit configuration or mp.messaging.incoming.name-of-channel.connector: connector-name in case of implicit config
connector name of the connector @Connector("connector-name")

Example connector accessing configuration:

@Connector("example-connector")
public class ExampleConnector implements IncomingConnectorFactory {

    @Override
    public PublisherBuilder<? extends Message<?>> getPublisherBuilder(Config config) {

        String firstPropValue = config.getValue("first-test-prop", String.class);1
        String secondPropValue = config.getValue("second-test-prop", String.class);

        return ReactiveStreams.of(firstPropValue, secondPropValue)
                .map(Message::of);
    }
}

Config context is merged from channel and connector contexts

Explicit Config for Messaging Connector

An explicit config for channel’s publisher is possible with Channel.Builder#publisherConfig(Config config) and for a subscriber with the Channel.Builder#subscriberConfig(Config config). The supplied Helidon Config is merged with the mandatory attributes and any implicit configuration found. The resulting configuration is then served to the Connector.

Example consuming from Kafka connector with explicit config:

String kafkaServer = config.get("app.kafka.bootstrap.servers").asString().get();
String topic = config.get("app.kafka.topic").asString().get();

Channel<String> fromKafka = Channel.<String>builder()12
        .name("from-kafka")
        .publisherConfig(KafkaConnector.configBuilder()
                                 .bootstrapServers(kafkaServer)
                                 .groupId("example-group-" + session.getId())
                                 .topic(topic)
                                 .autoOffsetReset(KafkaConfigBuilder.AutoOffsetReset.LATEST)
                                 .enableAutoCommit(true)
                                 .keyDeserializer(StringDeserializer.class)
                                 .valueDeserializer(StringDeserializer.class)
                                 .build())
        .build();

KafkaConnector kafkaConnector = KafkaConnector.create();3
Messaging messaging = Messaging.builder()
        .connector(kafkaConnector)
        .listener(fromKafka, payload -> {
            System.out.println("Kafka says: " + payload);
        })
        .build()
        .start();

Prepare channel for connecting kafka connector with specific publisher configuration → listener,
Channel → connector mapping is automatic when using KafkaConnector.configBuilder()
Prepare Kafka connector, can be used by any channel

Implicit config without any hard-coding is possible with Helidon Config following notation of MicroProfile Reactive Messaging.

Example of channel to connector mapping config with custom properties:

mp.messaging.incoming.from-connector-channel.connector: example-connector<1>
mp.messaging.incoming.from-connector-channel.first-test-prop: foo<2>
mp.messaging.connector.example-connector.second-test-prop: bar<3>

Channel → Connector mapping
Channel configuration properties
Connector configuration properties

Example consuming from connector:

Messaging.builder()
        .config(config)
        .connector(new ExampleConnector())
        .listener(Channel.create("from-connector-channel"),
                  s -> System.out.println("Consuming: " + s))
        .build()
        .start();

// > Consuming: foo
// > Consuming: bar

Re-usability in MP Messaging

As the API is the same for MicroProfile Reactive Messaging connectors, all that is needed to make connector work in both ways is annotating it with @ApplicationScoped. Such connector is treated as a bean in Helidon MP.

For specific information about creating messaging connectors for Helidon MP visit MicroProfile Reactive Messaging.

Kafka Connector

Maven dependency:

pom.xml

<dependency>
  <groupId>io.helidon.messaging.kafka</groupId>
  <artifactId>helidon-messaging-kafka</artifactId>
</dependency>

Reactive Kafka Connector

Connecting streams to Kafka with Reactive Messaging couldn’t be easier.

Explicit Config with Config Builder for Kafka Connector

Example of consuming from Kafka:

String kafkaServer = config.get("app.kafka.bootstrap.servers").asString().get();
String topic = config.get("app.kafka.topic").asString().get();

Channel<String> fromKafka = Channel.<String>builder()12
        .name("from-kafka")
        .publisherConfig(KafkaConnector.configBuilder()
                                 .bootstrapServers(kafkaServer)
                                 .groupId("example-group-" + session.getId())
                                 .topic(topic)
                                 .autoOffsetReset(KafkaConfigBuilder.AutoOffsetReset.LATEST)
                                 .enableAutoCommit(true)
                                 .keyDeserializer(StringDeserializer.class)
                                 .valueDeserializer(StringDeserializer.class)
                                 .build())
        .build();

KafkaConnector kafkaConnector = KafkaConnector.create();3
Messaging messaging = Messaging.builder()
        .connector(kafkaConnector)
        .listener(fromKafka, payload -> {
            System.out.println("Kafka says: " + payload);
        })
        .build()
        .start();

Prepare a channel for connecting kafka connector with specific publisher configuration → listener
Channel → connector mapping is automatic when using KafkaConnector.configBuilder()
Prepare Kafka connector, can be used by any channel

String kafkaServer = config.get("app.kafka.bootstrap.servers").asString().get();
String topic = config.get("app.kafka.topic").asString().get();

Channel<String> toKafka = Channel.<String>builder()12
        .subscriberConfig(KafkaConnector.configBuilder()
                                  .bootstrapServers(kafkaServer)
                                  .topic(topic)
                                  .keySerializer(StringSerializer.class)
                                  .valueSerializer(StringSerializer.class)
                                  .build())
        .build();

KafkaConnector kafkaConnector = KafkaConnector.create();3

Messaging messaging = Messaging.builder()
        .publisher(toKafka, Multi.just("test1", "test2").map(Message::of))
        .connector(kafkaConnector)
        .build()
        .start();

Prepare a channel for connecting kafka connector with specific publisher configuration → listener
Channel → connector mapping is automatic when using KafkaConnector.configBuilder()
Prepare Kafka connector, can be used by any channel

Implicit Helidon Config for Kafka Connector

Example of connector config:

application.yaml

mp.messaging:

  incoming.from-kafka:
    connector: helidon-kafka
    topic: messaging-test-topic-1
    auto.offset.reset: latest1
    enable.auto.commit: true
    group.id: example-group-id

  outgoing.to-kafka:
    connector: helidon-kafka
    topic: messaging-test-topic-1

  connector:
    helidon-kafka:
      bootstrap.servers: localhost:90922
      key.serializer: org.apache.kafka.common.serialization.StringSerializer
      value.serializer: org.apache.kafka.common.serialization.StringSerializer
      key.deserializer: org.apache.kafka.common.serialization.StringDeserializer
      value.deserializer: org.apache.kafka.common.serialization.StringDeserializer

Kafka client consumer’s property auto.offset.reset configuration for from-kafka channel only
Kafka client’s property bootstrap.servers configuration for all channels using the connector

Example of consuming from Kafka:

Channel<String> fromKafka = Channel.create("from-kafka");

KafkaConnector kafkaConnector = KafkaConnector.create();1

Messaging messaging = Messaging.builder()
        .config(config)
        .connector(kafkaConnector)
        .listener(fromKafka, payload -> {
            System.out.println("Kafka says: " + payload);
        })
        .build()
        .start();

Prepare Kafka connector, can be used by any channel

Channel<String> toKafka = Channel.create("to-kafka");

KafkaConnector kafkaConnector = KafkaConnector.create();1

Messaging messaging = Messaging.builder()
        .config(config)
        .publisher(toKafka, Multi.just("test1", "test2").map(Message::of))
        .connector(kafkaConnector)
        .build()
        .start();

Prepare Kafka connector, can be used by any channel

Don’t forget to check out the examples with pre-configured Kafka docker image, for easy testing:

Helidon messaging examples

JMS Connector

Maven dependency:

pom.xml

<dependency>
  <groupId>io.helidon.messaging.jms</groupId>
  <artifactId>helidon-messaging-jms</artifactId>
</dependency>

Reactive JMS Connector

Connecting streams to JMS with Reactive Messaging couldn’t be easier.

Explicit Config with Config Builder for JMS Connector

Example of consuming from JMS:

Channel<String> fromJms = Channel.<String>builder()// <1> <2>
        .name("from-jms")
        .publisherConfig(JmsConnector.configBuilder()
                                 .jndiInitialFactory(ActiveMQInitialContextFactory.class)
                                 .jndiProviderUrl("tcp://127.0.0.1:61616")
                                 .type(Type.QUEUE)
                                 .destination("se-example-queue-1")
                                 .build())
        .build();

JmsConnector jmsConnector = JmsConnector.create();3

Messaging messaging = Messaging.builder()
        .connector(jmsConnector)
        .listener(fromJms, payload -> {
            System.out.println("Jms says: " + payload);
        })
        .build()
        .start();

Prepare a channel for connecting jms connector with specific publisher configuration → listener
Channel → connector mapping is automatic when using JmsConnector.configBuilder()
Prepare JMS connector, can be used by any channel

Channel<String> toJms = Channel.<String>builder()12
        .subscriberConfig(JmsConnector.configBuilder()
                                  .jndiInitialFactory(ActiveMQInitialContextFactory.class)
                                  .jndiProviderUrl("tcp://127.0.0.1:61616")
                                  .type(Type.QUEUE)
                                  .destination("se-example-queue-1")
                                  .build()
        ).build();

JmsConnector jmsConnector = JmsConnector.create();3

Messaging messaging = Messaging.builder()
        .publisher(toJms, Multi.just("test1", "test2").map(Message::of))
        .connector(jmsConnector)
        .build()
        .start();

Prepare a channel for connecting jms connector with specific publisher configuration → listener
Channel → connector mapping is automatic when using JmsConnector.configBuilder()
Prepare JMS connector, can be used by any channel

Implicit Helidon Config for JMS Connector

Example of connector config:

application.yaml

mp.messaging:

  incoming.from-jms:
    connector: helidon-jms
    destination: se-example-queue-1
    session-group-id: session-group-1
    type: queue

  outgoing.to-jms:
    connector: helidon-jms
    destination: se-example-queue-1
    type: queue

  connector:
    helidon-jms:
      jndi:
        jms-factory: ConnectionFactory
        env-properties:
          java.naming.factory.initial: org.apache.activemq.jndi.ActiveMQInitialContextFactory
          java.naming.provider.url: tcp://127.0.0.1:61616

Example of consuming from JMS:

Channel<String> fromJms = Channel.create("from-jms");

JmsConnector jmsConnector = JmsConnector.create();1

Messaging messaging = Messaging.builder()
        .config(config)
        .connector(jmsConnector)
        .listener(fromJms, payload -> {
            System.out.println("Jms says: " + payload);
        })
        .build()
        .start();

Prepare JMS connector, can be used by any channel

Channel<String> toJms = Channel.create("to-jms");

JmsConnector jmsConnector = JmsConnector.create();1

Messaging messaging = Messaging.builder()
        .config(config)
        .publisher(toJms, Multi.just("test1", "test2").map(Message::of))
        .connector(jmsConnector)
        .build()
        .start();

Prepare JMS connector, can be used by any channel

Don’t forget to check out the examples with pre-configured ActiveMQ docker image, for easy testing:

Helidon Messaging Examples

AQ Connector

Maven dependency:

pom.xml

<dependency>
  <groupId>io.helidon.messaging.aq</groupId>
  <artifactId>helidon-messaging-aq</artifactId>
</dependency>

Reactive Oracle AQ Connector

Sending and Receiving

Example of producing to and consuming from Oracle AQ:

PoolDataSource pds = PoolDataSourceFactory.getPoolDataSource();1
pds.setConnectionFactoryClassName("oracle.jdbc.pool.OracleDataSource");
pds.setURL(jdbcUrl);
pds.setUser("frank");
pds.setPassword("frank");
AqConnector connector = AqConnector.builder()2
        .dataSource("test-ds", pds)
        .build();
Channel<String> toAq = Channel.<String>builder()3
        .name("toAq")
        .subscriberConfig(AqConnector.configBuilder()
                                  .queue("example_queue_1")
                                  .dataSource("test-ds")
                                  .build())
        .build();

Channel<String> fromAq = Channel.<String>builder()4
        .name("fromAq")
        .publisherConfig(AqConnector.configBuilder()
                                 .queue("example_queue_1")
                                 .dataSource("test-ds")
                                 .build())
        .build();

Messaging.builder()5
        .connector(connector)
        .publisher(toAq,
                   Multi.just("Hello", "world", "from", "Oracle", "DB!")
                           .map(Message::of))6
        .listener(fromAq, s -> System.out.println("Message received: " + s))7
        .build()
        .start();

Prepare Oracle UCP
Setup AQ connector and provide datasource with an identifier test-ds
Setup channel for sending messages to queue example_queue_1 with datasource test-ds
Setup channel for receiving messages from queue example_queue_1 with datasource test-ds
Register connector and channels
Add a publisher for several test messages to publish them to example_queue_1 immediately
Subscribe callback for any message coming from example_queue_1

Configuration

Configuration for Messaging Connector
Explicit Configuration with Config Builder for Kafka Connector
Implicit Helidon Configuration for Kafka Connector
Explicit Configuration with Config Builder for JMS Connector
Implicit Helidon Configuration for JMS Connector

Reference

Edit this page or Report an issue

OpenAPI UI

Helidon SE OpenAPI UI Support

Reactive Engine

Dependency-less reactive operators
